RGB red green blue 500mW-1200mW three-color synthetic white full-color cross laser module laser laser spotlight

RGB red green blue 500mW-1200mW three-color synthetic white full-color cross laser module laser laser spotlight parameter Working voltage: DC 12V Operating current: <5A Power: 500mW-1200mW Modulation signal voltage: 0-5V MODULATION SIGNAL FREQUENCY: 0-25KHZ Spot Mode: Line Line width: greater than 3mm (the farther the distance, the thicker the line width) Dimensions: 70*55*45mm(L*W*H) Driver board size: 48*32*15mm(L*W*H) Terminal specification: XH2.54mm 2P Interface description: On the driver board, the white interface is the 12V input power interface, and the yellow interface is the 12V output fan interface. The red interface is the red light modulation interface, the green interface is the green light modulation interface, and the blue interface is the blue light modulation interface. Operating temperature: -20°C~ 50°C Storage temperature: -40°C~ 85°C Note: Due to the special power of this product, if it is used for a long time, it must be equipped with sufficient heat dissipation to make the laser module work below 40°C. Application: It can realize 7 colors such as red, green, blue, red-green, red-blue, green-blue, red-green-blue (white light). It can be widely used in stage lighting, laser projection, outdoor lighting, laser positioning, spectral analysis, laser experiments, etc. 500mwRGB Cross: Red light: 638nm 200mw Green light: 505nm 100mw Blue light: 450nm 200mw Up to 6 meters in indoor working environment (6 meters long for horizontal and vertical lines of the cross) Up to 3 m in semi-outdoor (non-direct sunlight) working environment (3 m long for horizontal and vertical lines of the cross) The cross installation height can be used from 0 m to 8 m The wire is thin and uniform, and the collimation and stability are very high 1000mw RGB cross Red light: 638nm 200mw Green light: 505nm 150mw Blue light: 450nm 650mw Up to 10 meters can be used indoors (10 meters long for horizontal and vertical lines of the cross) Up to 5 m in semi-outdoor (non-direct sunlight) working environment (5 m long for horizontal and vertical lines of the cross) Up to 2.5 m in full outdoor (direct sunlight) working environment (2.5 m long horizontal and vertical lines of the cross) The cross installation height can be used from 0 to 10 meters The wire is thin and uniform, and the collimation and stability are very high 1200mWRGB Cross: Red light: 638nm 200mw Green light: 505nm 200mw Blue light: 450nm 800MW Up to 12 meters in indoor working environment (12 meters long for horizontal and vertical lines of the cross) Up to 6 m in semi-outdoor (non-direct sunlight) working environment (6 m long for horizontal and vertical lines of the cross) Up to 3 meters in an outdoor (direct sunlight) working environment (3 meters long for horizontal and vertical lines of the cross) The cross installation height can be used from 0 to 10 meters The wire is thin and uniform, and the collimation and stability are very high
