Model 42 Tube Mount Satin Stainless Steel up to 12.76mm

Model 42 316 grade Stainless Steel Suitable for exterior/interior use. Curved base for 42.4mm or 48.3mm tube. Suitable for 8mm, 8.76mm, 10mm, 10.76mm, 12mm, 12.76mm glass. Gaskets included. Please select glass thickness for correct gaskets. Removable support shoe included for additional support. Complies fully with safety standard DIN/EN 12600. Safety pin extra if required when removing support shoe. (See related products).12mm hole recommened if using Safety Pin. When using the support shoe place the clamp at the bottom of the glass for additional support, this can be removed to position the top or bottom clamp in an alternative location.Click the magnifying logo to view drawings in detailDimensions: 45mm x 57mm Finish: Satin
