DC Disconnect On/Off Switch 600A
Features
$ 27.00
Description
Switch Type: Single Circuit ON-OFF Color: Grey Switch Positions: 2 Battery Combine: No Alternator Field Disconnect: No Maximum Voltage: 32V DC Terminal Stud Torque: 220 in-lb (24.86 Nm) Continuous Rating: 600A Intermittent Rating: 900A (5 min) Cranking Rating: 1750A (30 seconds) Battery Inputs: 1 Cable Clearance For 4/0 AWG Cables: 1.10in (27.94mm) Cable Quantity to Meet Ratings: Two Cables Cable Size to Meet Ratings: 4/0 AWG (120mm²) Mounting Holes: Accept 1/4″ (M6) Screw Terminal Stud Size: 1/2″ (M12) Weight: 1.3 lbs
Additional information
