PILZ – 541160 541180 – Electrical Switches – ICDC-040424 – New Main Category: Electrical | Sub-Category: Switches | Status: New Original ComponentsPILZ Part Number: 541160 541180 | ICDC Internal Part Number: ICDC-040424 541160 541180 Description: PSEN cs4.1p 1switchArticle number: 541160RFiD safety switch, 2 safety semiconductor outputs, 8-pole M8 connector, 1 actuation direction, IP67, switching distance typ. 11 mm, Sao = 8 mm, Sar = 20 mm, package contents = 1 fully coded switch, programmable max 8 times.General dataApproval CE cULus Listed FCC IC EAC (Eurasia) TÜV Sensor principle Transponder Lev. coding sec. ISO 14119 high Classif. sec. EN 60947-5-3 PDDB Transponder coding Device compl. coded Series connection suitable Yup device version Sensor Technical dataElectrical dataSupply voltage (V) 24 VType of supply voltage U1 A.D Power consumption DC 1 WEntrancesNumber of entrances 2 DC voltage at the input 24 V DC Semiconductor outputsNumber of OSSD outputs 2 Number of signaling outputs 1 Electr. Insulation SC outputs No DC protection SC output Yup Cat. Use sec. EN 60947-1 DC-12 Environmental dataRoom temperature standard EN 60068-2-14 Room temperature -25 – 70 ° CNorm temp. warehousing EN 60068-2-1 / -2 Exposure at humidity sec. norm EN 60068-2-78 Humidity indication 93% RH at 40 ° C EMC acc. norm …. EN 60947-5-3 Vibrations sec. Norm … EN 60947-5-2 Acceler. shock sec. Standard 1 30g Overvoltage category III Degree of contamination 3 Degree of protection custody Switching distancesMod. Temp.dist.oper. Att. 1 -0.01mm / ° C Mod. Temp.dist.oper. Att. 2 -0.1mm / ° C Mod. Temp.dist.oper. Att. 3 -0.01mm / ° C Mod. Temp.dist.oper. Att. 4 -0.01mm / ° C Mechanical dataBending radius (for laying) K1 5 x Ø Flush mountable sensor Yes, follow instr. by Assembly Connection type M8, 8pol. bad Cable ducts Li9Y11Y 8 x 0.14 mm2 Mater. Super part case. PBT Height 37 mmLength 26 mmDepth 18 mmGross weight 50 gTransponderOperating frequency 122 kHz – 128 kHz PSEN cs4.1 1 actuatorNumero dell’articolo: 541180General dataApproval CE cULus Listed TÜV EAC (Eurasia) Sensor principle Transponder Lev. coding sec. ISO 14119 high Transponder coding Device compl. coded device version Actuator Technical dataEnvironmental dataRoom temperature standard EN 60068-2-14 Room temperature -25 – 70 ° CNorm temp. warehousing EN 60068-2-1 / -2 Exposure at humidity sec. norm EN 60068-2-78 Humidity indication 93% RH at 40 ° C EMC acc. norm …. EN 60947-5-3 Vibrations sec. Norm … EN 60947-5-2 Acceler. shock sec. Standard 1 30g Degree of protection custody Mechanical dataMater. Super part case. PBT Height 37 mmLength 18 mmDepth 18 mmNet weight 11 gGross weight 15 gTransponderOperating frequency 122 kHz – 128 kHz Contact us to discover 541160 541180. ICDCSPARES.COM offers new or overhauled original components, ready in stock to be shipped via DHL Express! Call us! Check our Electrical section to discover more about ICDC catalog: a large selection of industrial spare parts including Fuses, Electric Motors, Switches and Switches.Are you looking for industrial Switches? ICDC offers online a wide selection of Switches of the most important OEMs like EATON, ABB and DANFOSS, besides PILZ. ICDC, Your Industrial One Stop Shop for Components!
